SR-628BG

(HD), MIC
Color Black / White
Material Plastic-ABS , SPCC
Dimension 220 (W) x 483(H) x 445(D) mm
Weight(N/G) kgs / kgs
M/B type ATX , Micro ATX, ITX
5.25” Bay N/A
3.5” Bay 3 Hidden HDD
2.5” Bay 2 Hidden HDD/SSD
I/O USB3.0 x 2 , Audio (HD), MIC
Expansion 8
Cooling
(Fan option)
Top: 140/120mm x 2
Front: 140mm x 2 or 120mm x 3
Rear: 120mm x 1
PSU ATX PSII type, Case Bottom
  • Introduction
  • Features
Solleron has introduced a new concept for more versatility and adaptability to any configuration. The SR-628B mid tower ATX case gives PC enthusiasts flexible installation options and seamless operation. Users can keep their systems cool by assembling the chassis for superb airflow. This new chassis is the ultimate high end chassis suitable for any type of PC enthusiast.

‧Extensive water cooling support 240/280/360mm on the front and 240 on the top.
‧Maximum 6 x 120mm fans + 3 x 80mm fans
‧Dust-free interior filter cover top,front, and bottom air in takes
‧Maximum 3 x 3.5” + 2 x 2.5” HDD supported
‧Large cable management space on motherboard backside up to 30mm
‧Large transparent window side panels.
‧Support long graphic cards up to 360mm and CPU cooler height up to 160mm
